Haier HYCD-282C - Spare Parts of Cooling System

HYCD-282/282A/282C_Service Manual
6
5. Spare parts of cooling system
No. Part Code Name QTY Specification Remark
1 0074091262 Cool compressor 1 DB L88CY 220V/50Hz
0074000035 Cool compressor 1 ACCGVY57AG 220V/60Hz
2 0074000149 Freeze compressor 1 NL7CLX 220V/50Hz
0274000190 Freeze compressor 1 SC12CLX.2 220V/60Hz
3 0070701944 Condenser 2
4 0270700046 Cool evaporator 1 In the foam layer，can’t be
replaced.
5 0270700100 Freezer evaporator 1 In the foam layer，can’t be
replaced.
5 0270100458A Freezer evaporator 1 HYCD-282C In the foam
layer，can’t be replaced.
6 0074180002A Drier filter 2
7 0070301474 R600a - QTY：R600a 50g 220V/50Hz cool system
0070301474 R134a - QTY：R134a 150g 220V/60Hz cool system
8 0073010003 R404a - QTY：R404a 180g Freeze system
