Haier L19A11W Service Manual

3.NT68F631C
1 PD0 Push-Pull Structure with Schmitt Trigger Input
2 PA0/PWM2 Schmitt Trigger Input
3 PA1/PWM3 Schmitt Trigger Input
4 PA2/PWM4 Schmitt Trigger Input
5 PA3/PWM5 Schmitt Trigger Input
6 PA4*/PWM6* Open-Drain Structure with Schmitt Trigger Input
7 PA5*/PWM7* Open-Drain Structure with Schmitt Trigger Input
8 PA6*/PWM8* Open-Drain Structure with Schmitt Trigger Input
9 PA7*/PWM9* Open-Drain Structure with Schmitt Trigger Input
10 RSTB Active-Low Reset Input; with Schmitt Triger Input
11 P30/RXD GPIO Port-30 of Micro-Processor F8031
12 PD6 Push-Pull Structure with Schmitt Trigger Input
13 P31/TXD GPIO Port-31 of Micro-Processor F8031
14 PB2/ADC2/INTE0 Push-Pull Structure with Schmitt Trigger Input
15 PB3/ADC3/INTE1 Push-Pull Structure with Schmitt Trigger Input
16 P34/T0 GPIO Port-34 of Micro-Processor F8031
17 P35/T1 GPIO Port-35 of Micro-Processor F8031
18 PE0 Push-Pull Structure with Schmitt Trigger Input
19 PE1 Push-Pull Structure with Schmitt Trigger Input
20 OSCO 12MHz External Crystal OSC Output
21 OSCI 12MHz External Crystal OSC Input
22 GND Power Ground
23 PB0/ADC0 Push-Pull Structure with Schmitt Trigger Input
24 PB1/ADC1 Push-Pull Structure with Schmitt Trigger Input
25 PB4*/SCL0* Open-Drain with Schmitt Trigger Input
26 PB5*/SDA0* Open-Drain with Schmitt Trigger Input
27 PB6*/SCL1* Open-Drain with Schmitt Trigger Input
28 PB7*/SDA1* Open-Drain with Schmitt Trigger Input
29 PD5/CLMPO Push-Pull Structure with Schmitt Trigger Input
30 PD4/HALFI Push-Pull Structure with Schmitt Trigger Input
31 PD3/HALFO Push-Pull Structure with Schmitt Trigger Input
32 HSYNCI Horizontal and Composite sync Input
33 VSYNCI VSYNC/Interrupt Input; Schmitt Trigger Input
34 PD2/VSYNCO Push-Pull Structure with Schmitt Trigger Input
35 PD1/HSYNCO Push-Pull Structure with Schmitt Trigger Input
36 PC7 Push-Pull Structure with Schmitt Trigger Input
37 PC6 Push-Pull Structure with Schmitt Trigger Input
38 PC5/PATTO Push-Pull Structure with Schmitt Trigger Input
39 PC4/PWM1 Push-Pull Structure with Schmitt Trigger Input
40 PC3/PWM0 Push-Pull Structure with Schmitt Trigger Input
41 PC2/SOGI Push-Pull Structure with Schmitt Trigger Input
42 PC1* 5V Open-Drain Structure with Schmitt Trigger Input
43 PC0* 5V Open-Drain Structure with Schmitt Trigger Input
44 VCC +3.3V Power Supply Input
