-9-
AV EQUIPMENT
This TV provides two group of AV, one group of YPbPr for convenient connection to VCR, DVD or other video equipment.
Please refer to the owner's manual of the equipment to be connected as well.
You can use the input terminals on TV set rear as follows.
HDMI
Red (audio R)
White (audio L)
Red (Pr or Cr)
R
W
R
Blue (Pb or Cb)
Green (Y)
B
G
Yellow (video)
Y
G
B
R
Y/Pb/Pr EQUIPMENT
W R
G B R
W R
VIDEO EQUIPMENT
AV ADAPTER
CABLE
TO VIDEO OUTPUTS
VIDEO EQUIPMENT
TO VIDEO OUTPUTS
TO AUDIO OUTPUTS
Y
Y
W
W
R
R
Y
W
R
Y
W
R
USB
Antenna
AV Input
Video
L
-
audio
-
R
HDMI 1 VGA INPUTAV OUTPUT
Component Input
Y
Pb Pr
HDMI 2
L
- audio -
R
It can be connected to the following appliances: VCR, multi disc player, DVD, camcorder, video game or stereo system, etc...
YPbPr can support these video fomats: 480i, 576i, 480p, 576p, 720p, 1080i.
Note:
1. Sometimes it will not support in different device because the device supplys nonstandard signal.
2. When current source is TV, AV OUT signal is TV; when current source is AV, AV OUT signal is AV; other sources have no
AV OUT signal.
INSTALLATION
