-8-
DVI/ PC HDMI Input Signal Reference Table
When DVI port is being used: connect the DVI port of video device to your TV set with a DVI-to-HDMI line and set up the
output signal of the video device in accordance with table below.
When HDMI port is being used: connect the HDMI ports of your computer and TV set with one HDMI wire and set up the
output signal of the video device in accordance with table below.
Default HDMI Mode
Standard Resolution Horizontal Frequency (kHz) Vertical Frequency(Hz)
1 640 × 480 31.469 59.94
2 800 × 600 37.879 60.317
3 1024 × 768 48.363 60.004
4
1360 × 768
(* LE32B7500)
47.72 59.799
5
1920 × 1080*
(Only for LE48B7500/LE50B7500)
66.587 59.934
*Recommended resolution
Video Input Signal Reference Table
Connect the component signal or HDMI port of video device to your TV set and set up the output signal of the video device in
accordance with table below.
If your computer display card supports signals of video format then you can set up following output signal.
Default Component or HDMI Mode
Standard Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz)
SD 640 × 480p 25.175 60
SD 720 × 480i 15.734 60
SD 720 × 480p 31.5 60
SD 720 × 576i 15.625 50
SD 720 × 576p 31.25 50
HD 1280 × 720p 37.5 50
HD 1280 × 720p 45 60
HD 1920 × 1080i 28.125 50
HD 1920 × 1080i 33.75 60
FHD 1920 × 1080p 56.25 50
FHD 1920 × 1080p 67.5 60
Video Input Signal Reference Table
Video System Supported in TV and Video Modes
PAL B/G
Standard Denition Interface
You can also enjoy traditional program by using a DVD player or VCR Player. Connect this equipment to your TV via the
Composite Input on the back of your TV.
INSTALLATION
