Haier LE32B7500 User Manual

-4-
Main features
Used as Television, display terminal, PC display;
High luminance, wide viewing angle;
Can store 200 TV programs;
HDMI interface;
Multi-Media player (USB);
1
2
3
4
5
Accessories
LED LCD TV.................................1 User Manual....................................1
Base................................................1
Warranty Card.................................1 (For Hong Kong/Indonesia/
Philippines/India)
Screws............................................4 Quick Set Up Guide........................1
Remote Control..............................1 E-waste Guideline Booklet.............1 (Only for India)
Battery(AAA).................................2 AV adapter cable ............................1
Power Cord....................................1
Main parameter
Model Name LE32B7500 LE48B7500 LE50B7500
Resolution
1360 x 768 1920 x 1080 1920 x 1080
Aspect Ratio 16:9
TV System
PAL B/G
Video Signal System PAL/SECAM/NTSC
Receiving Channel 1-200
Input Power Voltage AC 100-240V 50/60Hz
Power consumption 60W 120W 130W
Audio Output Power(THD≤7%) 2 x 8W 2 x 10W 2 x 10W
Signal Input
Analog RGB(VGA) x 1
High-Denition Multimedia Interface (HDMI) x 2
Composite Video Input x 1
Composite AV Output x 1
Audio Input x 1
YCb (Pb )Cr (Pr) x 1
USB x 1
RF x 1
Horizontal denition (TV line)
Composite Video input >=350
Y Cb(Pb ) Cr(Pr) >=400
Ambient Temperature 0 to 45 degree Celsius
Wall mount
VESA mount pattern: 100 x
100mm
Screw: M4
Length: 18mm
VESA mount pattern: 200 x
200mm
Screw: M6
Length: 20mm
VESA mount pattern: 400 x
200mm
Screw: M6
Length: 18mm
This product does not include wall-mount braket module.
