ANTENNA
INSTALLATION
STEPS:
Be sure both the TV and computer are Power off.
1.Connect VGA and audio cable
2.Connect power cord
3.Power on the TV, switch to PC mode
4.Power on the PC
This sequence is very important.
PC
Note:
Aerial connections: IEC(female).
Input impendance: 75 unbalanced.
* The TV appearance subject to material object.
8
- 16 -
AC-INPUT
100-240V~ 50/60Hz
PC AUDIO VGA
HDMI2(ARC) HDMI3 SCART
LAN
