G Green (Y)
B Blue (Pb/Cb)
W White(AUDIO-L )
R Red (AUDIO-R, Pr/Cr)
Y Yellow (VIDEO)
AC-INPUT
100-240V~ 50/60Hz
PC AUDIO VGA
HDMI2(ARC) HDMI3 SCART
LAN
RF HDMI1
YPbPrAV IN HEADPHONE
COMMON INTERFACE(CI)
USB
USB OPTICAL
CVBS, DVD Player or other
machine with YPbPr/YCbCr.
GR
B
Audio/Video machine
with HDMI interfaces
R Y
W
CVBS, DVD Player or other
machine with CVBS/S-Video.
1WA N 2
3
4
Audio Receiver
