ANTENNA
INSTALLATION
Note:
Aerial connections: IEC (female).
Input impendance:75 unbalanced.
STEPS:
PC
Be sure both the TV and computer are powered off.
1.Connect a VGA and audio cable.
2.Connect the power cord.
3.Turn on the TV, switch to PC mode.
4.Turn on the PC.
-7-
HDMI1 HDMI2 USB VGA PC AUDIO
HEADPHONE
COAXIAL
R F
