Haier QHE16HYPFS - Refrigerator Use and Operation; Control Panel Overview

10 49-1000557 Rev. 0
ENGLISH
CONTROLS
A
Refrigerator Temperature Control Button
B
Freezer Temperature Control Button
C
Quick Cool Button
D
Quick Freeze Button
E
Sabbath Button
F
Lock Button
G
Quick Cool Indicator
H
Refrigerator Temperature Displayed in °F Indicator
I
Quick Freeze Indicator
J
Freezer Temperature Displayed in °F Indicator
K
Sabbath Mode Indicator
L
Lock Indicator
REFRIGERATOR USE
A
G
I
H
J
B
C
G
D
I
E
K
F
L
TOUCH PADS
The controls are touch pads, which respond when lightly
touched.
CONTROL PANEL LOCK
The control panel is automatically locked after 30 seconds
of nonuse. To change any settings the control panel must be
unlocked.
To Unlock the Control Panel:
Press and hold LOCK for 3 seconds. The
Lock indicator will turn OFF.
To Lock the Control Panel:
Press and hold LOCK for 3 seconds. The
Lock indicator will turn on.
TEMPERATURE DISPLAY
When no buttons or doors are operated for 30 seconds, all the
ÕÎÍöòñçìöóïäüóäñèï÷øõñòģ
When a button is pressed or a door opened, the LEDs on
display panel illuminate.
UNITS SELECT
The Units Select feature allows you to choose between
displaying the set temperature in either degrees Fahrenheit
(°F) or degrees Celsius (°C).
The default temperature unit is degrees Fahrenheit.
1. If locked, unlock the control panel by pressing and holding
LOCK for 3 seconds.
2. Press and hold FRIDGE and FREEZER
at the same time for 3 seconds. °C
will appear next to the temperature
display to indicate that the unit has
been changed to degrees Celsius.
3. To return to displaying the set
temperature in degrees Fahrenheit,
press and hold FRIDGE and FREEZER
at the same time for 3 seconds.
The °C will disappear from the
Temperature display.
READ AND SAVE THESE INSTRUCTIONS
