Chapter 4. Location of Controls and Components
4-1. Board Location
No. Parts number Description
4-1-2.L32K3
Service Manual
Model No.:
23
4-1-1.L26K3
A
B
C
Main Board(0090720080F)A Board DC1710E0100M
B Board
LCD Panel
0094001283A
C Board
Power Supply
0094001257MA
No. Parts number Description
Main Board(0090720080F)
A Board
B Board
LCD Panel
C Board
Power Supply
A
B
C
DC17S0E0500M
0094001264DA
0094001177A
