Service Manual
Model No.:
24
No. Parts number Description
4-1-3.L42K3
A
B
C
Main Board(0090720080K)A Board DC18K0E0300M
B Board
LCD Panel
0094001176B
C Board
Power Supply
0094001165BC
4-2.Mainboard
CNB3
CNE1
CNE2
CNF4
CNE3
CON30&CON31
CNC1
CNA2 CNF1
CNA1
4-2-1. Function Description:
Process signal which incept from exterior equipment then translate into signal that panel can display.
4-2-2-1.Mainboard of LB26R3,LB32R3,LB42R3,LB46R3
4-2-2.Connector definition
