10. PARTS LIST
1
2
3
4
Item No.
①
②
③
④
Part No.
B5056
B5057
B2300
B5059
Part Name
FP pick-up
FP pick-up wire (SS)
Heat resistant pad
adapter
Specifications
With pick-up wire (SS)
×2
●Optional parts
11. OPTIONAL PARTS (Nozzle) Unit: mm (in.)
HowtoUseaoldnozzle
1. Attach old nozzle to B5058 Conversion adaptor.
2. Attach B5058 (with old nozzle attached) to the heater pipe.
2014.9
MA02640XZ140906
