KID LOCKERS - ASSEMBLY INSTRUCTIONS - HKL151524-1
PACKAGE CONTENTS
ITEM
NO.
PART # DESCRIPTION QTY.
1 KDHF1518/24LV FRAME AND DOOR ASSEMBLY 1
2 KR1518 BACK 1
3 HTLC1515 TOP 1
4 KP1518 SIDES 2
5 KS1515 BOTTOM 1
6 KLG LEGS 2
7 MBT200 3/8" SLOTLESS BOLT 42
8 N201 HEX NUT 40
9 N110 DOME HEX NUT 2
10 RPE100 ESCUTCHEON PLATE 1
PG. 1
