EcoloAir Operation, Maintenance & Service Manual
OM-020/052017/rev5/EN
1
Pressure Transducer Air Tube
2 Pressure Transducer Air Tube Connecting Nut
3 Elbow
4 16 Gauge Top Panel
5 Elbow Lock Nut
6 Mullion
7 16 Gauge Bottom Panel
8 Structural Base
9 Fire Proof Door Gasket
10 Filter By-Pass Gasket
PRESSURE TRANSDUCER AIR TUBE PARTS
