Hamax A-head Bracket - Page 65

D
Check the top surface distance
EN Check if the steering stem is not more than 5 mm below
the top surface of the handlebar stem. If this is the case, remove
the spacers or exchange them with lower spacers (pic. 1).
If the steering stem is above the handlebar stem, you have to
add spacers, until the fork tube is max. 5 mm below the surface
of the handlebar stem (pic. 2).
AHEAD BRACKET for OBSERVER
Pic. 1
Pic. 2
OK
NOT
OK
