Parts and Features
Cover
Cooking Plate
Left Cooking
Plate Handle
Removable Ring
Assembly*
Top Heating Plate
Bottom
Heating Plate
Indicator Lights
Indicator Lights
Base
BEFORE FIRST USE: Lift cover to remove each ring assembly. Wash
both rings in dishwasher or in hot, soapy water. Rinse and dry. Wipe
top and bottom heating plates with a damp, soapy cloth. Remove
soap with a damp cloth; dry thoroughly. Spray rings with nonstick
cooking spray or wipe or brush with vegetable oil.
*To order parts:
US: 1.800.851.8900
www.hamiltonbeach.com
Canada: 1.800.267.2826
Mexico: 01 800 71 16 100
Right Cooking
Plate Handle
Cooking
Plate
Removable Ring
Assembly*
Red POWER
Light
Green PREHEAT
Light
Timer
Up Button
Down Button
Ring Handles
Left
Hinge
Right
Hinge
