3
Parts and Features
BEFORE FIRST USE: Lift cover to remove rings. Wash removable
rings in dishwasher or in hot, soapy water. Rinse and dry. Wipe top
and bottom heating plates with a damp, soapy cloth. Remove soap
with a damp cloth; dry thoroughly. Spray rings with nonstick cooking
spray or wipe or brush with vegetable oil.
Cover
Cooking Plate*
Cooking
Plate Handle
Base
*To order parts:
US: 1.800.851.8900
www.hamiltonbeach.com
Canada: 1.800.267.2826
Mexico:
01 800 71 16 100
Indicator Lights
Green PREHEAT Light
Red POWER Light
Timer
Up Button
Down Button
Removable
Bottom Ring*
Top Heating Plate
Removable
Top Ring*
Indicator Lights
Timer
Bottom
Heating Plate
