5
How to Assemble the Fryer
3
2
1
5
4
Place base on a stable, flat surface.
Insert oil tank into base.
For storage: Push handle into
basket and squeeze tines together
to remove handle.
Slide control panel with heating
element into base; making sure it
is in place. NOTE: Heater cannot
be turned on unless correctly
installed on base.
To assemble handle, squeeze tines
of handle together. Align tines with
round holes on metal bracket of
basket.
Release tines to allow them to
spread and then pull handle back
to lock into metal bracket.
