4
Parts and Features
To order parts, visit:
hamiltonbeach.com/parts
Before rst use: Wash all removable parts in hot, soapy water. Rinse and
dry. Brew one cycle with water on each side and discard water.
1 Carafe Side Lid
2
Carafe Water Reservoir (with
markings for measuring)
3 Brew Basket
4 Swivel Shower Head
5 Control Panel
6 Carafe
7 Warming Plate
8
Removable Cup Rest/Storage
Container
9
Cord Storage
10 Funnel
11
Single-Serve
Lid Latch
12
Removable Single-Serve
56 oz. Water Reservoir with
Removable Lid
13
Brown Removable Single-Serve
Brew Basket for Ground Coffee
with Hinged Lid and Handle
14
Gray Removable Single-Serve
Pod Holder with Handle
15
Gray Removable Needle Holder
with Black Seal
16
Piercing Needle
17 Black Seal
18 Single-Serve Side Lid
14
13
9
11
12
(on back)
1
6
18
4
2
3
5
7
8
10
15
16
17
