Parts and Features
1. Filter Basket
2. Clock and Controls (see below)
3. Carafe
4. Keep-Hot Plate
5. Water Level Guide
6. Top Cover
7. Water Reservoir
8. Swivel Shower Head
9. Cord Storage
10. Water Filter Lid*
11. Water Filter*
12. Water Filter Base*
13. Coffee Scoop
*optional feature on
selected models
PROG ON/OFFAUTO H M
AM
PM
ON/OFF Button
Hour Button
Program Button
Minute Button
AUTO Button with
Green Indicator
Light
Clock and Controls
Red On/Off
Indicator Light
