ITEM NO. QTY. PART NO. DESCRIPTION
1* 1 HDPR8-RX-0 WDMT, REAR CROSS TUBE
2* 1 HDPR8-LSFR-0 WLDMT, LOWER SIDE FRAME RT (HDPR)
3* 1 HDPR8-LSFL-0 WLDMT, LOWER SIDE FRAME LEFT (HDPR)
4* 2 HDPR8-CFUPL-0 PTD ASSY, 8' COMP FRT UPRIGHT LFT
5* 2 HDPR8-CFUPR-0 PTD ASSY, 8' COMP FRT UPRIGHT RT
6* 2 HDPR8-RUP-0 WLDMT, REAR UPRIGHT
7* 1 HDPR8-USFL-1 WLDMT, UPR SIDE FRAME LEFT (HDPR)
8* 1 HDPR8-CPU-0 PTD ASSY - COMPONENT PULL UP (HDPR)
9* 1 HDPR8-USFR-1 WLDMT, UPR SIDE FRAME RIGHT (HDPR)
10* 1 HDPR8-TX-0 WLDMT, TOP CROSS BEAM (HDPR)
11 1 HD-SDL-00 PLATED WDMT, SHORT DOCK-LOCK
12 48 WASH.5STAR 1/2" INTERNAL LOCK WASHER
13 20 WASH.375SAE 3/8" SAE FLAT WASHER
14 46 H-BACK-WASH BACKING WASHER
15 10 NUT.375LOCK 3/8" THICK LOCK NUT
16 42 NUT.5LOCK 1/2" THICK LOCK NUT
17 40 HHB.5X4.5 1/2 X 4 1/2 BOLT
18 10 HHB.375X4.5 3/8 X 4.5 BOLT
19 2 HHB.5X3.5 1/2 X 3 1/2 BOLT
20 10 ANG-WT-HORN-ASSY ANGLED WEIGHT HORN
21 2 HDPR8-CBC-0 PTD ASSY, BAR CATCH
22 1 HDPR8-CBSL-1 PTD ASSY, BAR SUPPORT LEFT
23 1 HDPR8-CBSR-1 PTD ASSY, BAR SUPPORT RIGHT
24 1 WARNING LARGE-V LARGE WARNING VERT.
25 1 SERIAL NUMBER SERIAL NUMBER
26 1 PATENT PATENT DECAL
