Hammer Strength HDPR8 - Left Front Upright Assembly

5
6
3
4
1
2
Page 6
________________________________________
LEFT FRONT UPRIGHT ASSEMBLY - HDPR8-CFUPL-0*
HDPR8 HEAVY DUTY 8 FOOT POWER RACK
ITEM NO. QTY. PART NO. DESCRIPTION
1* 1 HDPR8-FUP-0 WLDMT, 8' UPRIGHT
2 1 SQ-24-1 3 X 3 END CAP
3 1 HD-LH-ADJ-RACK-01 HD ADJUSTMENT RACK, LEFT
4 4 3/8 X 4 FHSCS 0.375 X 4" FLAT HEAD CAP SCREW
5 4 WASH.375SAE 3/8" SAE FLAT WASHER
6 4 NUT.375LOCK 3/8" THICK LOCK NUT
