Description Wire
Network / Ethernet RJ 45 Jack
Alarm output (zero potential) Brown
Alarm output (zero potential) White-brown
Alarm input (zero potential) Blue
Alarm input (zero potential) White-blue
External speaker, negative pole (-) Yellow
External speaker, positive pole (+) Pink
Power supply, negative pole (-) Black
Power supply, positive pole (+) Red
Please take care when connecting the wires. Connecting the wires the wrong way may destroy the BirdGuard.
Step 9: Final assembly
Screw in the 433 MHz RFID Antenna and 2.4 GHz WiFi Antenna into the desired threads on the back of the
BirdGuard. Mount the BirdGuard on the mounting stand.
Step 10: Activating the BirdGuard
Switch on the power to the wires leading to the assembly location again. You can see whether you have connected
the power supply properly from the Diagnostic LED (it lights up once the power has been connected correctly for up
to five minutes and continuously in night-vision mode). The BirdGuard is ready for operation (booting up process, any
software updates, etc.) once it has emitted a short diagnosis sound from the integrated loudspeaker. This may last
for up to 5 minutes. Should you not hear a beep, please check the power supply. Please also check whether you
have used a wall-plug power-supply and not PoE and whether you have connected the positive pole and negative
pole to the BirdGuard correctly.
Step 11: Downloading and installing the app
Download the “DoorBird” app by Bird Home Automation onto your mobile device from the Apple app store or Google
Play store. You can always find the most up-to-date version of the App manual on www.doorbird.com/support
If you use WiFi for connecting the BirdGuard to your Internet router, first go to “Settings > WiFi Setup” and follow the
instructions.
If you have finished the WiFi set-up or have connected the BirdGuard to your Internet router by means of a network
cable, go to “Settings > Add device” and click on the QR code icon in the “User” field. Scan the user QR code found
on the “Digital Passport” that accompanies the BirdGuard.
If you have problems adding the BirdGuard to the App please check if the BirdGuard is online (
www.doorbird.com/checkonline ). If the BirdGuard is not online, please check the WiFi or network cable connection
again.
Since Apple uses very high quality microphones, loudspeakers and digital audio components that are perfectly in
tune with one another, the voice quality with an iPhone or iPad is usually noticeably better than with an Android
smartphone or Android tablet.
Diagnostic-LED
