16
Drawbar Effects - Leslie
Accessing the LESLIE Edit Menu Using the Shortcut:
Touch and hold any of the three LESLIE Touch Tabs. After approximately 1 second, you will see the screen
shown below.
You are now in the LESLIE Edit Menu. You may now use the PAGE NAVIGATION Touch Buttons in conjunction
with the VALUE Rotary Control to make various changes to the parameters of the digital Leslie. These changes are
explained starting on the next page.
If you followed the instructions on the previous page, you should now see Page 1 of the LESLIE Edit Menu.
Leslie Parameters
Your Hammond SKX has a special group of Leslie Parameters. Using these special Leslie features, you can define
different characteristics of how the built-in digital Leslie effect will perform. The Leslie Parameters are:
1. Slow Speed for both Horn and Bass Rotor.
2. Fast Speed for both Horn and Bass Rotor.
3. Rise Time for both Horn and Bass Rotor.
4. Fall Time for both Horn and Bass Rotor.
5. Brake Time for both Horn and Bass Rotor.
6. Level or Volume for both Horn and Bass Rotor.
7. Microphone Settings (Angle and Distance)
