Pre-Assembly
PLANNING ASSEMBLY
Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included and Package
Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts.
TOOLS REQUIRED (NOT INCLUDED)
Safety Goggles Safety Hat Level Gloves Step Ladder Phillips Screwdriver
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
AA
BB
CC
DD
EE
FF
GG
HH
Part Description Quantity Part Description Quantity
AA M6x35 bolt 24 EE M6 nut 16
BB M6x15 bolt 184 FF Hex wrench 2
CC M5x15 screw 8 GG Ground stake 16
DD M6x30 bolt 16 HH Screwdriver 1
To Next Page
