5 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Assembling the mesh cover
□ Insert the handle (A) into the hole on the top of the
mesh cover (B).
□ Attach the handle (A) to the mesh cover (B) using a
nut (BB). Securely tighten with an M6 wrench (not
included).
CAUTION:
Wear gloves during assembly.
Assembling the stand
□ Attach the legs (E) to the fire bowl (D) using
M6 x18 mm bolts (AA).
□ Do not tighten the bolts at this step.
Assembly
D
E
AA
B
BB
To Next Page
