HAMPTON BAY MILL VALLEY - Pre-Assembly; Planning Assembly; Hardware Included

3
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA Bolt (M6x20) 8
BB
CC
4
12
Washer
Bolt cap
PLANNING ASSEMBLY
It will take one
person about 15 minutes to complete the assembly process.
HAMPTONBAY.COM
DD
12
Bolt (M6x35)
AA
BB
CC
DD
EE
1
Hex wrench
EE
