USER MANUAL For MULTISCAN P2
Chapter 2 - 14
24. Internal ULTRAPLEXER (P/N. 3001-0032)
Chrysler 12+16Pin cable 15Pin D Sub (to Main Cable => Scanner) to
12+16Pin adaptor (to Sebring/Stratus vehicle side adaptor)
25. Fiat 3Pin (P/N. 3001-0031)
Used for the communication with the
OBD1 generation cars of Fiat Group.
Vehicles side DLC is located in various
place on the vehicle but generally around
dashboard.
(Can be supplied as an optional part)
26.
DC POWER CABLE (P/N. 3001- )
