2 MINIVATOR 2000 INSTALLATION MANUAL
Pre-installation check list
1 Check that all of the required components
are available.
a Track Drawing e Power pack
b Track f Seat and upholstery
c Stanchions g Fitting kit
d Feet
Note: Before assembly you must ensure
that all of the required track is to the correct
specification, the stanchions supplied are the
correct length, the correct number have been
supplied and the corresponding number of
feet are available. In order to do this you need
to cross reference the items supplied to the
drawing supplied. Please refer to Appendix 4
for further details.
2 Installation tools required
Minivator 2000
installation manual
Smart Seat
Issue No of this manual is 0611-1
ORIGINAL LANGUAGE ENGLISH
• Loading toggle
• Loading bars
• Shorting links
• 8mm Spanner
• 13mm Spanner
• 17mm Spanner
• No. 3 Pozidrive
• Nylon electricians
pull through – at
least the length of
the track
• Track Lubricant:
Copaslip, or
Gleitmo 350
• 2.5mm Allen key
• 3mm Allen key
• 4mm Allen key
• 5mm Allen key
• 6mm Allen key
(ball ended)
• Superglue (inside
track only)
Note: The installation engineer must check
with Minivator for the latest installation manual
issue number.
