207
98
90
2
9
2
IMPORTANT!
TO MEET DUE/INSTALLATION DATES
THE DATA SHEET ATTACHED MUST
BE SIGNED AND RETURNED BY RETURN.
UP
811
405
2148 837
2
0
8
586
2037
2
9
6
0
8
USER DETAILS
Standing Ht:
1850 mm
Seated Ht: 800 mm
Back To Knee: 550 mm
DRAWING NUMBER:
CONTRACT / CUSTOMER
DRAWN:
Hand of Rail :
Rail Colour :
DATE:
DRAWING NUMBER:
DO NOT SCALE
This drawing and any information or descriptive matter set out hereon are the confidential and copyright property of MINIVATOR LTD.
and must not be disclosed, loaned, copied or used for manufacturing, tendering or any other purpose without their written permission.
ALL DIMENSIONS IN MM UNLESS OTHERWISE STATED
rtc-12345
Fred Smith
dd/mm/yy
Grey
RIGHT
rtc-12345
REV
COMMENTS
BY
DATE
Track Bolts :
24
Track Sections Used
Parts for Build
Fitting Kit
Joining plugs :
16
Aditional
(section/ by stanchion)
Charge Points :
Standard
End Stops :
Magnets :
0
MK2
IR
Hand Sets :
Number needed :
Stanchion Feet
2
Standard :
Lower :
Fan :
11
1
0
Wall Brackets :
Heavy Duty Kit :
NO
Wire needed (m) :
0
7
Wood Screws for feet :
36
Stanchion bolts :
24
Located on :
11
Located on :
Located on :
Seat Type :
Space Saver
Client name
REFERENCE
Client reference
1
2
3
4
5
13
11
10
9
6
7 8
MINIVATOR 2000 INSTALLATION MANUAL 47
Appendix 4
External track details
1
TRACK PARTS
REQUIRED
2
FITTING KIT DETAILS
3
SEAT TYPE
4
SIDE OF STAIRS
FOR INSTALLATION
LOOKING FROM
THE BOTTOM
5
TRACK COLOUR
6
APPLICATIONS
ENGINEER
7
CUSTOMER
REFERENCES
8
DRAWING NUMBER
9
TRACK SIDE VIEW
10
CLIENT DETAILS
11
TRACK ISOMETRIC
VIEW
12
TRACK PLAN VIEW
13
SPECIAL
INSTRUCTIONS
14
TRACK FRONT
VIEW
