Handicare ReTurn7500 - Testing Standing Function; Training Standing Function; Farther Back in the Chair

Exploded view - Rising ladder and leg support
Ladder:
Number Name
1 Rising ladder
Leg support:
Number Name Size
1 Holder for leg support
2 Bushing Ø28/Ø25,5x32 mm svart POM
3 Leg support
4 Mounting fixture for leg support
5 Screw K6S ISO 7380 M6x16
6 Locking pin
Component list
4
SystemRoMedic
TM
5
1
2
3
4
6
pos Title Art. nr
1
Raising ladder 90001117
