8 HANDICARE SIMPLICITY INSTALLATION MANUAL
Figure 17
Figure 16
Figure 15
Feet positioning
Second foot
Splice
Third/
last foot
Feet positioning
Items required: Tools required:
• None • 13mm Spanner
• 13mm Socket
1 Slide the track to the side of the stairs that
it will be finally located to position the feet.
The feet should be positioned so that they
are touching the stringer (Figure 15).
Note: If the stringer does not extend to the
tread, i.e. it overhangs the staircase, use a
plumb line to mark a position on the stairs.
The feet should all be positioned in this way.
