Adjusting and connecting
Preparations before rear
connection H54
The stove is prepared for top
connection on delivery. When
connecting from the rear, the cover and
connection must be swapped around.
• Dismantle the cladding as
instructed
previously, see page 55.
• Tap out the knock out in the stove’ s
back panel, remember to protect the
floor.
• Then unscrew both the connector
and the cover.
• Switch places and reinstall the
screws.
Handöl 54 / 54T
Preparations before rear
connection H54T
The stove is prepared for top
connection on delivery. When
connecting from the rear, the cover
and connection must be swapped
around.
• Unscrew both the upper screws
and lift off the back.
• Tap out the knock out in the
stove’ s back panel, tap from the
inside of the back, remember to
protect the floor.
• Then unscrew both the connector
and the cover.
• Switch places and reinstall the
back.
