-18-
ROTATING DRIVELINE
CONTACT CAN CAUSE DEATH
KEEP AWAY!
DO NOT OPERATE WITHOUT-
• ALL DRIVELINE, TRACTOR AND
EQUIPMENT SHIELDS IN PLACE.
• DRIVELINES SECURELY
ATTACHED AT BOTH ENDS.
• DRIVELINE SHIELDS THAT
TURN FREELY ON DRIVELINE.
PTO ASSEMBLY – Care must be taken to keep the male and
female driving elements well lubricated and free sliding. Failure to
observe this precaution will result in excessive pressure being
required to collapse or extend the assembly while subject to oper-
ating torque. This excessive force may damage or displace the
jackshaft bearings. DO NOT lubricate the shield surfaces. The
shield surfaces must be kept dry, as dirt accumulation on them will
quickly cause these units to bind and not rotate. Care should also
be taken to be certain that the rotating integral shields are not
dented or damaged, as this also will result in excessive force
being applied against the jackshaft. Damaged shields also cause
obvious difficulties when installing the assembly. If at any time the
shields do not turn freely, they should be checked to determine
the cause, and repaired or cleaned. To avoid damage to the main
drive bearings, avoid turning sharp corners while PTO is running.
Start PTO slowly to avoid damage to the drive train.
OPTIONAL EQUIPMENT
REAR PAN
The rear pan is optional on the ModelS 80 &125 spreaders.
LUBRICATION GUIDE (Continued)
MODEL 80 MODEL 125
