Spray ball
09513, 09514, 09515, 09516, 09517
BA_009500.03_EN
2019-03-05 Albert Handtmann Armaturenfabrik GmbH & Co. KG 4 / 6
Type 09513 - horizontal tank, perforation 180° to the top
DN capacity [m³/h] 1.5 - 2.0 bar Ø spray circle [m]
10 1.5 – 2.0 1.0
25 12 – 14 3.0
32 16 – 18 4.0
50 25 - 29 6.0
Type 09514 - horizontal tank, perforation 180° to the bottom
DN capacity [m³/h] 1.5 - 2.0 bar Ø spray circle [m]
25 13 – 15 3.0
32 17 – 19 4.0
50 23 - 27 6.0
Type 09515 - vertical tank, perforation 220° to the top/*240° for DN 10
DN capacity [m³/h] 1.5 - 2.0 bar Ø spray circle [m]
10* 3.0 – 3.5 1.0
25 15 – 17 3.0
32 22 – 25 4.5
50 30 - 35 6.0
65 56 – 64 10.0
Type 09516 - vertical tank, perforation 220° to the top
DN capacity [m³/h] 1.5 - 2.0 bar Ø spray circle [m]
50 43 - 50 10.0
Type 09517 - vertical tank, perforation 360°
DN capacity [m³/h] 1.5 - 2.0 bar Ø spray circle [m]
10 3 - 4 1.0
50 48 - 55 8.0
65 60 - 67 10.0
