handtmann 33501 User Manual

Safety relief valves
33501, 33502, 33503, 33521, 33601, 33602, 33603, 33621
Perfomance Data
BA(k)_033501.06
14 / 30 Albert Handtmann Armaturenfabrik GmbH & Co. KG 2023-07-27
5 Perfomance Data
Fluid: Air
33501/33521/33601/33621
33501/33503/33521/33601/33603/33621
Pressure
[bar-g]
Throughput [Nm³/h]
DN 15
DN 25
DN 40
DN 50
DN 65
DN 80
1
137
369
736
1.054
1.917
3.035
2
208
560
1.119
1.603
2.915
4.615
3
279
752
1.502
2.152
3.913
6.195
4
210
944
1.885
2.701
4.911
7.775
5
253
1.136
2.268
3.250
5.909
9.355
6
295
1.328
2.651
3.799
4.107
10.935
7
338
1.520
3.034
4.348
4.700
7.196
8
380
1.711
3.417
4.896
5.293
8.105
9
423
1.903
3.800
5.445
5.887
9.013
10
466
2.095
4.183
5.994
6.480
9.922
Fluid: Water
33501/33521/33601/33621
33501/33503/33521/33601/33603/33621
Pressure
[bar-g]
Throughput [kg/h]
DN 15
DN 25
DN 40
DN 50
DN 65
DN 80
1
3.970
10.760
26.012
42.430
65.910
107.260
2
5.610
15.210
36.790
60.010
93.210
151.690
3
6.870
18.630
45.050
73.490
114.160
167.210
4
7.940
21.520
52.030
84.860
131.820
193.080
5
8.870
24.060
58.160
94.870
147.370
215.870
6
9.720
26.370
63.710
103.940
161.450
236.470
7
10.500
28.460
68.820
112.260
174.380
255.420
8
11.220
30.440
73.570
120.010
186.420
273.060
9
11.900
32.290
78.040
127.290
197.730
289.620
10
12.540
34.040
82.260
134.180
208.420
305.290
