HANGCHA CPD30-A - Page 18

14
to the traveling motor.
Accelerator pedal [24]
Provides infinitely variable control travel
speed.
As the accelerator pedal is slowly pressed, the
drive motor start turning and the forklift truck
will start to move. According to the force
applied to the pedal, the speed is adjusted with
not steps.
CAUTION
 Loosen the accelerator pedal when
truck is working, truck can make
soft brake.
WARNING
 Before open the key switch to press
the accelerator pedal, the more
function digital indicator shall show
alarm information. Then you must
release the accelerator pedal.
Steering wheel [25]
It‟s can control the forklift steering.
The steering hand-wheel is operated in the
conventional manner, that is, when the wheel
is turn right, the truck will turn to the right;
when the wheel is turn left, the truck will turn to
the left. The steer wheels are located at the
rear of the truck. These cause the rear of the
truck to swing out when a turn is made.
WARNING
 This truck is provided with the
power steering, so heavy
hand-wheel operation is caused
when the steering motor comes to a
stall. To put the power steering in
operation again, restart the steering
motor without delay.
Key switch [26]
Switches control current on and off.Removing
the key prevents the truck from being switched
on by unauthorised personnel.
The key switch has two “on/ off” position, you
should push the Direction switch lever to
neutral and loose the accelerator pedal, then
turning the key switch to “on” position
clockwise.
CAUTION
 Turning the key switch “on” does
not make the forklift truck move, if
the Direction switch lever is not in
the neutral position or the
accelerator pedal is pushing.
 Error code maybe appear, don’t
worry about it.
 The Direction switch lever should
be returned to neutral and move you
foot from the accelerator pedal.
Then the truck can be operated.
 Then the error code should be
disappeared.
Locker of battery cover hood [27]
Fixed the battery cover.
Locking bolt of battery side plate [28]
Locking the side plates on both of the battery
box.
Air spring of battery cover [29]
When the battery cover hood opened, to
support the cover hood. When closed the
cover hood, press the red button, at the same
time hard to press the cover hood.
Fuse box [30]
