FOREWORD
Thanks for you purchasing our XC seies Lithium Battery Counterbalanced
XC series electric four-wheel forklift truck is our company’s new product. It has the character of
small turning radius, beautiful shape, small dimensions, low gravity, good stability, superior
performance.
This operation manual is the explanations that how to use XC series Lithium Battery
Counterbalanced. It will instruct you how to operate safety and precautionary maintenance. To f
ensure safety and exert the truck’s potential, all the personnel that in charge of operation,
maintenance and management must read this manual thoroughly before starting work with the
forklift.
As the improvements of products of our company, maybe there are some differs between this
operation manual with your forklift truck.
If you have any questions please keep touches with HANGCHA GROUP CO., LTD. sales
department or let the agents know.
This series of truck has passed CE certification.
Model
Traction
control
Pump
control
Traction motor
Pump motor
Rated capacity(t) / Load
center (mm)
ACS80M-
330C-35P
ACS80M-
330C-35P
YDQ9-4-4820 YDB16-4-4820
CPD18-XD4-SI16
1.8/ 500
CPD20-XD4-SI21
ACS80M-
330C-35P
ACS80M-
330C-23P
YDQ11-4-4822/
HPQ11-4HC-C
YDB21-4-4820
2.0/ 500
CPD25-XD4-SI21
2.5 / 500
CPD30-XD4-SI21
ACS80L-
440C-35P
ACS80M-
330C-23P
3.0 / 500
CPD35-XD4-SI21
3.5 / 500
CPD20-XD4-SI25
ACS80L-
440C-35P
ACS80M-
330C-35P
HPQ15-4HC-A HPB25.4-4
2.0/500
CPD20-XD4-SI26
HPQ16.6-4HC TSA200-200-214
CPD25-XD4-SI25
ACS80L-
440C-35P
ACS80M-
330C-35P
HPQ15-4HC-A HPB25.4-4
2.5/500
CPD25-XD4-SI26
HPQ16.6-4HC TSA200-200-214
CPD30-XD4-SI25
ACS80XL-
550C-35P
ACS80L-
440C-35P
HPQ15-4HC-A HPB25.4-4
3.0/500
CPD30-XD4-SI26
HPQ16.6-4HC TSA200-200-214
CPD35-XD4-SI25
ACS80XL-
550C-35P
ACS80L-
440C-35P
HPQ15-4HC-A HPB25.4-4
3.5 /500
CPD35-XD4-SI26
HPQ16.6-4HC TSA200-200-214
Warning
In order to ensure the combination of the charging gun plug and the lithium battery socket, and to
prevent the lithium battery gun from loosening during the charging process, the lithium battery gun
is provided with a lock, so it cannot be pulled out by force pulling. Therefore, after charging is
completed, the lock must be loosened. Only when the button on the charging gun is pressed can
the lock be released and the charging gun can be pulled out smoothly.
To successfully remove the lithium battery charging gun, you must press the button on the gun.
Failure to do so will result in damage to the gun and socket.
©
05/2020 HANGCHA GROUP CO., LTD
