SPECIFICATIONS:

RANGE 0.0 to 14.0 pH

RESOLUTION 0.1 pH

ACCURACY

(@20°C/68°F) ±0.1 pH

TYPICAL EMC DEVIATION ±0.1 pH

ENVIRONMENT 0 to 50C

(32 to 122F); 95% RH

CALIBRATIONCALIBRATION

CALIBRATION Manual, at two points through

offset and slope trimmers

BATTERY TYPE 4 x 1.5V alkaline (included)

BATTERY LIFE approx. 1700 hours

of continuous use

DIMENSIONS 175 x 41 x 23 mm

(7.9 x 1.8 x 1")

WEIGHT 78 g (2.7 oz.)

ACCESSORIES:

HI 73106 Spare electrode

HI 77400P pH 4.01 & 7.01 calibration kit

(5 x 20 mL, each)

HI 77700P pH 7.01 calibration kit

(10 x 20 mL)

HI 770710P pH 7.01 & 10.01 calibration kit

(5 x 20 mL, each)

HI 7004M pH 4.01 buffer solution

(230 mL bottle)

HI 7007M pH 7.01 buffer solution

(230 mL bottle)

HI 7010M pH 10.01 buffer solution

(230 mL bottle)

HI 70300M Storage solution (230mL)

HI 7061M Electrode cleaning solution

(230mL bottle)

HI 731326 Calibration screwdriver (20 pcs)

IS98107-R3 09/01

ELECTRODE REPLACEMENT:

The electrode can be easily replaced in the following

way:

• Slide off the battery cover.

• Remove the screw on the back of the

pHeppHep

pHep

located below the battery compartment and slide

off the whole internal part of the tester.

• To remove the electrode proceed as follows:

Remove the fastening screw on the front (1) to

loose the electrode. The internal circuit is con-

nected to the electrode through two wires (one

for the glass sensor and one for the reference).

Remove the two small screws (2 & 3) which

fasten the two connecting wires to their sock-

ets.

• Remove the electrode and

replace it with a new

HI73106.

• Connect the new electrode

as follows:

first fasten the screw on the

front (1) to attach the elec-

trode to the circuit. Insert

the two small wires into

their sockets and fasten the

two screws (2 & 3).

• The new electrode is supplied with four new O-

rings (4). Make sure they are placed properly

(as shown on the above drawing) before

reinserting the circuit into the plastic casing.

• Reinsert the internal circuit with the new

electrode into the plastic casing.

• Fasten the screw on the back below the

battery compartment.

Internal circuit and electrode:

• Reinsert the battery compartment cover.

• Perform a new calibration before using the

pHep pHep

pHep again.

pHep

®®

HI 98107

Pocket-sized pH Meter

HI73106

ONE YEAR WARRANTY & SERVICEABLE:ONE YEAR WARRANTY & SERVICEABLE:

ONE YEAR WARRANTY & SERVICEABLE:

Covered by

one yearone year

one year warranty against defects in work-

manship and materials, this tester is now completely

serviceable. Contact your dealer for further information.

The

pHep pHep

pHep is in compliance with the CE directives EN

50082-1, EN 50081-1 and EN 61010-1.

pHeppHep

pHep

®®

is a registered Trademark of "Hanna Instruments"
