Hanns.G HW191 User Manual

User’s Manual
MAKING CONNECTIONS
CONNECTING TO A PC
Turn off your computer before performing the procedure below.
1. Connect one end of the VGA cable to the back of the monitor and connect the other end to the
computer’s D-Sub port.
2. Connect one end of the DVI-D cable (Dual input mode optional) to the back of the monitor and
connect the other end to the computer’s DVI-D port.
3. Connect the audio cable between the monitor's audio input and the PC's audio output (green
port).
4. Plug one end of the AC power cord to the LCD monitor’s AC input socket, and the other end to
the Wall outlet.
5. Turn on your monitor and computer.
Figure.2. Connecting to a PC
1. VGA Input 2. DVI-D Input (optional)
3. Audio Input 4. Power AC Input
10

Hanns.G HW191 Specifications

General

Brand	Hanns.G
Model	HW191
Category	Monitor
Language	English
