User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
LCD Panel Size 48.2cm(19.0")
Pixel pitch 0.294mm(H) x 0.294mm(V)
Video H-Frequency 31KHz – 80KHz
V-Frequency 56 – 75Hz
Display Colors 16.2M Colors
Max. Resolution 1280 x 1024 @75Hz
Plug & Play
VESA DDC2B
TM
ON Mode
≤36W
Power Saving Mode
≤2W
EPA ENERGY
STAR
®
OFF Mode
≤1W
Input Connector
D-Sub
DVI-D (Dual-Input Model)
Maximum Screen Size
Hor. :376.32mm;
Ver. :301.06mm
Power Source 100~240VAC, 50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 5° to 35°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 85%
Dimensions
416(W)×414(H)×207(D) mm
16.38”(W)×16.3”(H)×8.15”(D)
Weight (GW/NW)
6.5 kg / 5.3 kg
14.3 lb / 11.7 lb
***The above specification is subject to actual product specification and is subject to
change without prior notice.
20
