User’s Manual
10
MAKING CONNECTIONS
CONNECTING TO A PC
Turn off your computer before performing the procedure below.
1. Connect one end of the VGA cable to the back of the monitor and connect the other end to the
computer’s D-Sub port.
2. Connect one end of the DVI-D or HDMI to DVI cable (optional) to the back of the monitor and
connect the other end to the computer's DVI-D port.
3. Connect one end of the HDMI cable (optional) to the back of the monitor and connect the other
end to the computer’s HDMI port.
4. Connect the audio cable between the monitor's audio input and the PC's audio output (green
port).
5. Plug one end of the AC power cord to the LCD monitor’s AC input socket, and the other end to
Wall outlet.
6. Turn on your monitor and computer.
HZ194A HZ201D; HZ221D; HZ231D; HZ251D
HZ201H; HZ231H; HZ251H HZ281H
Figure.2. Connecting to a PC
1 Power AC Input 2 Audio Input
3 VGA Input 4 DVI Input
5 HDMI Input 6 Earphone
