User’s Manual
10
MAKING CONNECTIONS
CONNECTING TO A PC
You can setup your monitor with the below suggested connections. Ensure your monitor is off during
this process.
1. Connect one end of the HDMI cable to the back of the monitor and connect the other end to the
computer’s HDMI port.
2. Connect one end of the VGA cable (optional) to the back of the monitor and connect the other
end to the computer’s VGA port.
3. Connect one end of the HDMI to DVI cable (optional) to the back of the monitor and connect the
other end to the computer’s DVI port.
4. Connect the audio cable between the monitor's audio input and the PC's audio output (green
port).
5. Plug one end of the AC power cord to the LCD monitor’s AC input socket, and the other end to
Wall outlet.
6. Turn on your monitor and computer.
Figure.2. Connecting to a PC
1 HDMI Input 2 HDMI Input
3 VGA Input 4 AUDIO IN
5 USB 6 Earphone
