3. Bottom View
When the computer is running or charging, heat is produced inside the Notebook and
transferred to the back of the chassis by the heat dissipation system for cooling. The
transformer may also produce a lot of heat during normal use as well. The Notebook
and its transformer should therefore not be placed in the lap or on any other body part
for prolonged periods during use. Also avoid placing the Notebook on a soft surface
(e.g. sofa) as it might block the heat vents and interfere with cooling.
C
A
U
T
I
O
N
!
No. Item Description
1 Battery Lock Slide inwards to lock the battery in place. Slide outwards to
unlock battery.
2 Battery Pack Replaceable battery pack. Serves as the Notebook's power
supply
3 Battery Latch Push outwards to release battery for removal
4 Hard Disk Cover The Hard Disk Cover protects the internal hardware. Open
to exchange device
5 Memory Cover The cover is to protect the memory from damage. Open to
exchange device
4
5
3
1
2
