Hans Grohe Metris E Series User Manual

Safety Notes
Glovesshouldbewornduringinstallationtoprevent
crushingandcuttinginjuries.
Theshowersystemmayonlybeusedforbathing,
hygienicandbodycleansingpurposes.
Thehotandcoldsuppliesmustbeofequal
pressures.
Installation Instructions
Thettingmustbeinstalled,ushedandtestedafter
thevalidnorms.
Iftheinstantaneouswaterheatercausesproblemsor
ifyouwishtoincreasethewaterow,theEcoSmart
®

(owlimiter)locatedbehindtheaeratorcanbe
removed.
Technical Data
This mixer series-produced with EcoSmart
®
(ow
limiter)
Operatingpressure: max.1MPa
Recommendedoperatingpressure: 0,1–0,5MPa
Testpressure: 1,6MPa
(1MPa=10bar=147PSI)
Hotwatertemperature: max.80°C
Recommendedhotwatertemp.: 65°C
Hansgrohemixerscanbeusedtogetherwith
hydraulicallyandthermicallycontrolledcontinuousow
heatersiftheowpressureisatleast0,15MPa.




•
•
English
Cleaning (seeenclosedbrochure)
Operation (seepage35)
Spare parts (seepage36)
Assembly see page 31
Dimensions (seepage34)
Donotusesiliconecontainingaceticacid!
Special accessories
specialtool(58085000)orderasanextra
Installationkitorderasanextra
Toadjustthehotwaterlimiteronsinglelever
mixers,pleaseseepage33.Noadjustment
isnecessarywhenusingacontinuousow
waterheater.
Symbol description
Flow diagram
(seepage34)

withEcoSmart
®

withoutEcoSmart
®
Test certicate (seepage35)
4
