Hansen APP08 - Purge Gas Solenoid Valve

13
APP-001b
APR 2007
PURGE GAS SOLENOID VALVE
Figure 7
1/4" PURGE GAS GAUGE VALVE
WIDE OPEN DURING OPERATION
CLOSED FOR SERVICING PURGER
PURGE GAS
1/32" (0.8 MM) DIA
METERING ORIFICE
(0.07 BAR)
PURGE GAS TO WATER BUBBLER OR
TO CUSTOMER SUPPLIED WATER BOTTLE
CHECK
VALVE
SOLENOID VALVE
DISC INSTALLED IN
THE CHECK VALVE
1 PSID
