Hansen APP08 User Manual

15
APP-001b
APR 2007
PARTS LIST
MECHANICAL
HLLSW Float Switch Assembly
20-1772 Water Bubbler Assembly, antisyphon (w/end connections)
20-1186 Metering Valve
20-1198 Metering Valve Seal Kit
20-1648 Metering Valve Strainer
20-1737
Screen Assembly Replacement Kit for above strainer, includes:
20-1535 Screen Assembly
78-0016 Strainer Cap Gasket
ST050 Water Purge Line Strainer
78-1001
Screen Assembly Replacement Kit for above strainer, includes:
78-0005 Screen Assembly
78-0016 Strainer Cap Gasket
70-1059 Plunger Kit for all purger solenoid valves
20-1183 Check Valve, 1 psid (.07 bar) with orifice
20-2489 Check Valve, 1 psid (.07 bar) no orifice
20-1185 Check Valve, 225 psid (15.5 bar)
20-1214 Check Valve Seal Kit for 1 psid and 225 psid check valves
20-1311 Liquid Drainer
20-2432 Vapor Trap
H5600R Relief Valve, 300 psi
ELECTRICAL
70-1088 Solenoid Coil, DIN plug - 115V, 50/60 Hz, 16 Watt
20-2428 Electric Heater, 115V, 50/60 Hz, 750 Watt
20-2477 Electric Heater, 230V, 50/60 Hz, 750 Watt
20-1279 Fuse, 2 amp, 115V purger
20-2402 Fuse, 15 amp, 115V purger
20-1695 Fuse, 3 amp, 220V purger
20-2463 Fuse, 8 amp, 220V purger
20-2403 PLC, 12 position
20-2416 PLC, 6 position
20-2405 PLC module, thermocouple input
20-2406 PLC module, current input
20-2407 PLC module, AC output
20-2408 PLC module, AC input/output
20-2409 PLC control console
20-2410 Heater Contactor
20-2411 Cable, PLC to Control Console
PSU 100-240VAC:24VDC Power Supply
HPT717 Water Concentration Sensor
SPSN-1 Liquid Make-up Level Sensor
SPSN-1 Low Liquid Level Sensor
20-2429 Plate Heater Temperature Sensor
20-2430 Liquid Temperature Sensor
20-2431 Evaporator Shell Temperature Sensor
75-3002 Pressure Transducer
20-2404 PLC module, AC input
20-2413 PLC module, DC input/relay output
20-2464 Transformer 220/115V
