15
APM-001e
AUG 2015
PARTS LIST FOR APM (AMMONIA)
ELECTRICAL
Control Board 20-1836
Shield for above 20-2271
Ground Wire for above 20-2270
Power Board 20-1845
3A (amp) fuse (5mm x 20mm) Type F
for Power Board
20-1698
Cable, Control Board 20-1837
Pressure Transducer 20-1857
Temperature Sensor 20-2303
High Side Level Sensor 77-0796
Drainer & Low Side Level Sensor 77-0535
Solenoid Coil Kit, 230V for DIN plug 70-1093
Solenoid Coil Kit, 115V for DIN plug 70-1092
MECHANICAL
Solenoid Tube/Plunger Kit 70-1059
Water Solenoid Valve (D), Less Coil HS2B/1
APM Bubbler 20-1959
Strainer/Orifice Screen Assembly Kit
includes Strainer/Orifice Screen
Assembly and necessary O-Rings
20-2177
Water Flow Controller 20-1985
Removable Seat/Orifice Kits
For Solenoid Valve (B) or (C) 70-1068
For Solenoid Valve (A) 70-1069
80 psid Check Valve 20-2379
Foul Gas/Liquid Line Strainer Kits
include Strainer Basket and O-Ring
78-1010
PARTS LIST FOR APMF (HALOCARBON)
ELECTRICAL
Control board 20-1836
Shield for above 20-2271
Ground Wire for above 20-2270
Power board 20-1845
3 amp fuse (5mm x 20mm)
Fast-Acting for Power board
20-1698
Cable, control board 20-1837
Pressure transducer 20-1857
Temperature sensor 20-2303
High side level sensor 77-0796
Drainer and low side level sensor 77-0794
Solenoid coil kit, 230V with DIN plug 70-1093
Solenoid coil kit, 115V with DIN plug 70-1092
MECHANICAL
Solenoid tube/plunger kit 70-1059
APMF bubbler 20-2282
Strainer/orifice screen assembly kit
includes strainer/orifice screen assembly
and necessary o-rings
20-2285
Removable seat/orifice kits
For solenoid valve (C) 70-1068
For solenoid valve (A) or (B 70-1069
80 psid check valve 20-1949
Foul gas/liquid line strainer kit
Includes strainer basket and o-ring
78-1010
ORDERING INFORMATION, PURGER
Cat. No. Description
APM
Auto-Purger M, 4 points,
for ammonia systems
APMF
Auto-Purger M, 4 points,
for halocarbon systems
To Order: Specify catalog number, refrigerant and voltage.
Standard voltage is 115V 50/60Hz;230V 50/60Hz, is available.
CSA and CE mark available.
ORDERING INFORMATION, OPTIONAL VALVE
PACKAGE
Cat. No. Description
VPM Valve Package for ammonia systems
VPMF Valve Package for halocarbon systems
To Order: Specify catalog number and refrigerant. The VPM
optional isolation valve package consists of three flanged
welded assemblies which include the necessary shut-off
valves and gauge valves for the foul gas line, suction line,
and liquid line. The VPMF for halocarbons also includes
filter dryers and moisture indication sight glasses.
