3. Connect the LPG gas supply pipe to the water
heater. Only use suitable approved gas supply pipe.
Fit the pipe onto the hose barb and secure using a
hose clamp.
4. Position the water heater through the cut out
opening.
4. Remove sealing frame and coat with non
hardening mastic on the side facing the vehicle - do
not use silicone
5. Fasten sealing frame plate to the cowl body using
4 self cutting screws.
6. Mount the grille. Press the entire cowl assembly
onto the vehicle wall and fasten with 6 screws.
7. Screw the water heater secularly to the floor of
the vehicle with at least two shackle plates with the
screws provided 5.5 x 25, on suitable base
(plywood panel, laminated wood strips or metal
base.
Installation of the water connectors
