Hansen HLM2 User Manual

15
A100b
JAN 2009
INSTALLATION DIMENSIONS
INCHES (MM)
HLM2
HLM6
GAS ALERT SYSTEM
7.39
(188)
6.30
(160)
.38
(9.6)
5.94
(151)
6.54
(166)
1.06
(27)
1.125
(28)
1.16
(29.5)
1.06
(27)
3xM20
M16/PG9
5.26"
(134)
2.72"
(69)
6.30"
(160)
2.56
(65)
.62
(16)
2.07
(53)
4.13
(105)
.173 DIA (4,4)
MOUNTING HOLE
3 PLACES
.29
(7)
2.93
(78)
6.37
(162)
.358 DIA (9,1)
MOUNTING HOLE
3.10
(79)
7.58
(191)
.49 DIA (5X)
(12)
AUDIBLE ALARM
KEY SWITCH
HIGH LEVEL
ALARM RESET
.173 DIA (4,4)
MOUNTING HOLE
3 PLACES
.358 DIA (9,1)
MOUNTING HOLE
9.50
(241)
10.38
(264)
5.19
(132)
.56
(14)
.29
(7)
8.58
(218)
9.56
(243)
3.30
(84)
2.80
(71)
HIGH LEVEL
ALARM RESET
AUDIBLE ALARM
KEY SWITCH
.49 DIA (5X)
(12)
